Canon imagePROGRAF TM-305 36" Large Format Inkjet Printer

Get high precision lines, crisp text and vivid colour, even on plain paper, with the 5-colour pigment Lucia TD ink system. Image processing controls ink bleeding, while enhanced water resistance makes media easier to handle, indoors and out.





Printer Type

5-Color 36-inch Printer

Number of Nozzles

Total: 15,360

MBK: 5,120 nozzles

C, M, Y, BK: 2,560 nozzles each

Nozzle Pitch

1,200 dpi

Non-firing nozzle detection and compensation

OS Compatibility

Windows® 7, 8.1, 10 (32/64bit)

Windows® Server 2008 R2, 2012, 2012 R2, 2016 (64bit)

Macintosh OS X v10.10.5-v10.12x

Standard Interfaces

USB 2.0 High-Speed

10/100/1000 Base-T/TX

Wireless LAN (IEEE 802.11 b/g/n)

Direct USB Thumb Drive Printing

Ink Droplet Size

5 picoliter

Ink Capacity

130 ml or 300ml per color

Ink Droplet Size

Pigment Ink

Color Set

Pigment: Matte Black, Black, Cyan, Magenta, Yellow

Buffer Ram

128 GB (Virtual), 2GB (Physical)

Media Width

Cut Sheet - 8- 36

Roll Feed - 8 - 36

Media Thickness

0.07-0.8mm

Maximum Roll Print Length

Roll Feed - 59' (18 meters)

Maximum Media Roll Diameter

5.9 (150mm)

Borderless Printing Width

8”, 10, 12”, 14, 16” 17, 20”, 24, 36 B4 (10.12/257 mm), A3 (11.69/297 mm), A3+ (12.95/329 mm), A2 (16.54/420 mm), B2 (20.28/515 mm), A1 (23.39/594 mm), B1 (28.66/ 728 mm), A0 (33.11/841 mm)

Paper Feed Method

Roll Feed: One Roll, Top-loading, Front Output

Cut Sheet: Top Loading, Front Output

Languages

SGRaster, HPGL/2, HP-RTL, JPEG, PDF

Noise Level Approx

Operation: 44 dB (A)

Standby: 35 dB (A) or less

Acoustic Power: 6.0 Bels

Physical Dimensions

42 x 51 x 35

Weight

approx.134 lbs (roll holder included, no inks, no print heads)

Power Source

AC100-240V (50-60Hz)

Power Consumption

Maximum: 69W or less

Standby 3.6W or less

Power Off: 0.3W or less (Compliant with Executive Order)

Operating Environment

Temperature: 59°-86° F (15°-30° C) Relative Humidity: 10-80% (No Condensation)

User-replaceable items

Print Head (PF-06)Maintenance Cartridge (MC-31)Ink Tanks (PFI-120/PFI-320)Cutter Blade (CT-08)

Software Included

TM Unified Printer Driver, Accounting Manager, Apple AirPrint, Canon Print Service, Device Management Console, Direct Print & Share, Free Layout Tool, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, PosterArtist Lite for Windows, Optimized Driver for AutoCAD, Canon PRINT Inkjet Selphy, Easy Photo Print Editor †
