Product Summary:
 Up to Print Speed 170mm/sec.
Up to Print Res 203 x 203 dpi
40, 58 & 80mm Media Width
95 Alphanumeric Charecter
Automatic Cutting Method
USB, USB Host & Serial Port
One Year Return to Base Warranty
Product Description:
As the TM-L90LF prints both liner-free labels and receipts in order to improve the user's operational efficiency and total cost of ownership (TCO). As the printer works with adhesive-backed media, users are able to accurately label food and drink orders - thereby increasing customer satisfaction and user accuracy.
Order processing speed
With print speeds of up to 170mm/sec, the potential benefits to the user are clear: fast order (and checkout) processing, faster drive-through services and improved customer satisfaction.
Built-in taken sensor
The next label prints automatically as the printed one is taken.
Flexible installation
Users can position the printer in the most convenient spot, thanks to a choice of vertical, horizontal or wall-mounted (using optional bracket) installation.
Saves paper
The TM-L90LF features improved paper reduction functionality that includes back feed capability, line feed adjustment and a smaller sized font. It can be set up to cut through adhesive areas, which saves paper. To further reduce paper consumption, the automatic top margin reduction function prints the top of the next receipt before cutting the current one when printing continues after auto cutting. It supports 1.5-inch, 2-inch or 3-inch media widths.
Features
Built-in taken sensor Automatic next label printing
Media flexibility 40, 58 and 80mm media widths
Speed Print speeds of up to 170mm/sec
Paper-saving Improved paper reduction function
Easy installation Three mounting positions
Technical Specs
Power Description
Power Source Power Adapter
Interfaces/Ports
USB Yes
Serial Port Yes
USB Host Yes
Miscellaneous
Platform Supported PC
Country of Origin China
Noise Level 52 dB
Cutter
Cutting Method Automatic
Cutter Yes
Cutter Life 1000000 Cuts
Cut Type Partial Cut
Technical Information
Application/Usage Desktop
Recommended Use Label Print
Print Head Life 75KM
Installation Horizontal/Vertical
Print Color Capability Monochrome
Mean Time Between Failures (MTBF) 41.1 Year
Mean Cycles Between Failures (MCBF) 35000000
Character Sets 37 International
128 x 11 Graphic
ANK
95 Alphanumeric
Maximum Print Resolution (dpi) 203 x 203
Physical Characteristics
Form Factor Wall Mount
Height 203 mm
Width 140 mm
Depth 148 mm
Product Color Dark Grey
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number C31C412682
Manufacturer Website Address http://www.epson.com.au
Manufacturer Epson Corporation
Product Model TM-L90LF (682)
Product Name Liner-Free Thermal Label Printer
Product Series TM-L90
Brand Name Epson
Media Types & Handling
Maximum Roll Diameter 102 mm
Media Type Black Mark
Label
Liner-free Label
Receipt
Media Sensor Black Mark Sensor
Cover Open Sensor
Paper End Sensor
Maximum Label Width 80 mm
|
